NZXT H5 Flow RGB Edition White Compact Mid-tower Airflow Case

NZXT H5 Flow RGB – Compact ATX Mid-Tower PC Gaming Case – High Airflow – F360 RGB Core Included – CC-H52FW-R1 – 360mm Front & 240mm Top Radiator Support – Cable Management – Tempered Glass – White

The H5 Flow RGB boosts airflow and GPU cooling with its perforated PSU shroud, mesh panels, and large radiator support—all in a compact mid-tower form factor.

The PSU shroud is perforated on the side and bottom, enabling optimal air intake from two 120mm fans (not included).
Supports up to a 360mm radiator in front and a 240mm radiator up top for powerful liquid cooling potential.
Ultra-fine mesh on the top, front, and side panels creates maximum airflow and filters dust.
Equipped with a front-mounted F360 RGB Core (CV) single-frame fan and rear-mounted F120Q (CV) fan for strong out-of-the-box cooling and lighting.
Effortlessly route and conceal cables using the wide channels, hooks, and straps.

Motherboard Support: E-ATX (Up to 277 mm wide), ATX, Micro-ATX, Mini-ITX
Enclosure Type: Mid-Tower
Case Material: SGCC Steel, Ultra-Clear Tempered Glass (White)
Height (with feet): 465 mm / 18.31 in
Width: 225 mm / 8.86 in
Depth: 430 mm / 16.93 in
Weight: 7.63 kg / 16.82 lb

Inside the Box
H5 Flow RGB
F360 RGB Core (CV)
F120Q (CV)
Installation accessories
User guide

Key Specs
Motherboard Support E-ATX (Up to 277 mm wide), ATX, Micro-ATX, Mini-ITX
Enclosure Type Mid-Tower
Case Material SGCC Steel, Ultra-Clear Tempered Glass (White)

Dimensions
Height (with feet) 465 mm / 18.31 in
Width 225 mm / 8.86 in
Depth 430 mm / 16.93 in
Weight 7.63 kg / 16.82 lb

Compatibility & Clearance
CPU Cooler Height Up to 170 mm
GPU Length Up to 410 mm
PSU Length Up to 200 mm
Cable Management Up to 28.7 mm
Top Radiator Up to 240 mm (280 mm with low-profile memory)
Top Mounted Radiator + Fan Thickness Up to 55 mm

Front Ports
USB 3.2 Type-A 1
USB 3.2 Gen 2×2 Type-C (20 Gbps) 1
Headset Audio Jack 1

Expansion Slots
Standard 7
Vertical 0

Drive Bays
2.5″ 2
3.5″ 1

Fan Support
Front 3 x 120 mm / 2 x 140 mm (1 x F360 RGB Core Case Version included)
Top 2 x 120 mm / 2 x 140 mm
Bottom 2 x 120 mm
Rear 1 x 120 mm (1 x F120Q Case Version included)

Radiator Support
Front Up to 360 mm
Top Up to 240 mm (280 mm with low-profile memory only)

Fan Specs – F360 RGB Core (Case Version)
Model F360 RGB Core (Case Version)
Speed 1,700 ± 200 RPM
Airflow 50.1 CFM
Static 1.27 mm-H?O
Noise 23.3 dBA
Fan Connector 3-pin DC

Fan Specs – F120Q (Case Version)
Model F120Q (Case Version)
Speed 1,350 ± 150 RPM
Airflow 60.2 CFM
Static 1.05 mm-H?O
Noise 24.1 dBA
Fan Connector 3-pin DC

Manufacturer’s Product-Link
