Arctic Freezer 36 A-RGB Multi Compatible Tower CPU Cooler with A-RGB Black

Arctic Freezer 36 A-RGB – Single-Tower CPU Cooler with Push-Pull, Two Pressure-optimised 120 mm P Fans and ARGB Lighting, Fluid Dynamic Bearing, 200–2000 RPM, 4 Heatpipes, incl. MX-6 Thermal Compound

CONTACT FRAME FOR INTEL LGA1851 AND LGA1700: Improved contact pressure distribution through Intel mounting frame for efficient heat transfer thanks to even CPU contact surface
HIGH-PERFORMANCE FOR HIGH-END CPUs: With its 4 offset heat pipes, the single-tower cooler enables fast heat transfer to the heat sink. There, the heat is efficiently dissipated by pressure-optimized 120 mm fans.
INNOVATIVE FAN MOUNTING: Innovative click installation system makes it easier to install the cooler or replace the fans. The Freezer 36 is compatible with most 120 mm fans
SIDE-FLOW HEAT SINK: By opening the fins on the side, the pull fan draws additional cool air out of the case through the heat sink, optimises ventilation and increases cooling efficiency
DIGITAL A-RGB: The 12 A-RGB LEDs placed along the fan hub and the transparent rotor with its closed design ensure even and rich illumination

High-Class Finish with Aluminum Top Plate
With its push-pull configuration, the Freezer 36 A-RGB not only impresses with its efficient cooling performance, but also with its design. The soldered ends of the heatpipes are concealed by the screwed aluminum cover, allowing it to blend seamlessly into any PC setup and highlight both performance and appearance.

Freezer 36 – Tested and Confirmed by Intel
Intel has tested and confirmed the Freezer 36 on the i9 in the Enthusiast and Desktop category. In these tests, Intel considered both the mounting with contact frame and the cooler’s performance.

Future-Proof Compatibility
The Freezer 36 A-RGB is multi-compatible with Intel and AMD sockets. Intel will release the new Arrow Lake processors on the LGA1851 socket in the future. We guarantee full compatibility. All Freezer 36 can be used with the new LGA1851 socket from Intel without limitation.

Improved Fan Mounting
Thanks to the innovative mounting system, booth fans are effortlessly mounted in the heatsink using a click system. This mounting method eliminates the need for fan clips, making it easier to install the cooler or replace the fans, even if the cooler is already installed. The Freezer 36 A-RGB is therefore compatible with most 120 mm fans.

LGA1851 | LGA1700 Contact Frame
Intel’s Independent Loading Mechanism (ILM) deforms the CPU by pressing it into the socket at two points with over 40 kg. This causes pressure in the PCB, the DIE and the solder layer between the DIE and IHS (Integrated Heat Spreader). With high thermal load, this can lead to long-term problems. The mounting frame from ARCTIC does not deform the CPU, reduces the mechanical load on the CPU massively, is quick and easy to install and allows the cooler to be screwed onto the CPU’s backplate. As a result, mechanical stress on the mainboard and CPU is minimized, cooling performance remains consistent and installation is quick and uncomplicated.

High-Quality Bearing
Thanks to a combination of alloy and lubricant developed in Germany, friction within the bearing is minimized and greater efficiency is achieved. In addition to preventing lubricant loss, wear on the pin and sleeve is also minimized. In this way, less heat is generated, less bearing noise is produced and the service life of the fan is significantly extended.

Optimized Heatsink
The fins of the heatsink are open at the side and allow the pull fan to draw additional cool air out of the pc case through the heatsink. This side-flow design achieves even more efficient ventilation.

P-Fans – High Static Pressure and Impressive Colors
ARCTIC relies on the proven P-fans with A-RGB illumination. The P-series, which is known for its powerful performance, is particularly suitable for use on heat sinks and radiators. The 12 built-in LEDs can be controlled independently of each other and are compatible with the common A-RGB standards of leading motherboard manufacturers. The fans can therefore be fully illuminated directly via the A-RGB mainboard connection and synchronized with the lighting of other hardware.

ARCTIC’s partner SignalRGB offers a comprehensive solution for synchronization and individual configuration of the illumination.

General Specifications
Compatibility
Intel: LGA1851 – LGA1700
AMD: AM5 – AM4
PI – NNPI: 245 – 219
TIM: MX-6 (0.8 g)
Warranty: 6 Years
Operating Ambient Temperature: 0-40 °C
Dimensions: 104 (L) x 126 (W) x 159 (H) mm
Weight: 917 g

Heatsink
Heatpipes: 4x Ø6 mm, Copper
Fin Stack: 59x 0.4 mm, Aluminum

Fans
Fan: 2x P12 PWM PST A-RGB
Speed: 200 – 2000 rpm, PWM Controlled (0 rpm below 5 % PWM)
Bearing: Fluid Dynamic Bearing
Current | Voltage: 0.11 A | 12 V DC
Cable Lenght: 200 mm + 80 mm Splitter Cable
Connector: 4-Pin PWM-Connector + 4-Pin Plug

RGB
LEDs: 12x A-RGB LEDs
Current – Voltage: 0.40 A | 5 V DC
Cable Length: 200 mm + 80 mm Splitter Cable
Connector: 3-Pin A-RGB-Connector + 3-Pin Plug
