Cooler Master MasterBox TD500 V2 Black Case with Polygonal Mesh Front Panel

Cooler Master MasterBox TD500 TD500V2-KGNN-S00 Mesh V2 Airflow ATX Mid-Tower Black with Polygonal Mesh Front Panel w/ controller, Crystalline Tempered Glass, E-ATX up to 10.5″, Three 120mm CF120 ARGB Lighting Fans

Polygonal Mesh
Crystalline Tempered Glass
Triple ARGB CF120 Fans
Dual 360mm Radiator Support
Versatile Cooling Options
Room For Upgrades
ARGB/Fan Hub Included

USB 3.2 GEN 2 TYPE C SUPPORT
USB 3.2 Gen 2 Type C port built into the I/O panel allows multi-purpose, streamlined data transmission.

REMOVABLE TOP PANEL
The top panel is entirely removable for improved access during assembly and ease of mounting of cooling solutions.

TOOL-FREE CRYSTALLINE TG SIDE PANEL
Featuring a crystalline tempered glass side panel, completely toolless for quick access to the internals.

Support for up to 7 120mm fans and 3600m front and top radiator support

PSU SHROUD WITH REMOVABLE COVER
MasterBox TD500 Mesh V2’s removable PSU cover allows users to freely decide whether to showcase or keep their PSUs hidden.

HARDWARE COMPATIBILITY
MasterBox TD500Mesh V2 is natively compatible with ITX, M-ATX and ATX motherboards.
E-ATX motherboards, such as SSI-CEB models, are compatible with dimensions up to 12″ x 10.7″.

Materials – Exterior Steel, Mesh, Plastic
Materials – Left Side Panel Tempered Glass
Dimensions (L x W x H) 499 x 210 x 500mm (incl. Protrusions), 430 x 210 x 477mm (excl. Protrusions)
Volume 50L (excl. Protrusions)
Motherboard Support Mini ITX, Micro ATX, ATX, SSI CEB, E-ATX*, (*up to 12″ x 10.7″ motherboards, may impact cable management feature)
Expansion Slots 7
3.5″ Drive Bays 2
2.5″ Drive Bays 3
I/O Panel – USB Ports 2x USB 3.2 Gen 1, 1x USB 3.2 Gen 2 Type C
I/O Panel – Audio In / Out 1x Audio Jack
I/O Panel – Other 1x ARGB Fan Hub
Pre-installed Fans – Front 3x 120mm CF120 ARGB
Pre-installed Fans – Rear N/A
Fan Support – Top 3x 120mm, 2x 140mm
Fan Support – Front 3x 120mm, 2x 140mm
Fan Support – Rear 1x 120mm
Radiator Support – Top 120mm, 140mm, 240mm, 280mm, 360mm, (recommended maximum thickness -55mm)
Radiator Support – Front 120mm, 140mm, 240mm, 280mm, 360mm
Radiator Support – Rear 120mm
Clearance – CPU Cooler 165mm/6.49″
Clearance – PSU 200mm, (Recommended up to 170mm)
Clearance – GFX 410mm / 16.14″
Cable Routing – Behind Motherboard Tray 19mm / 0.74″
Dust Filters Front, Top, Bottom
Power Supply Support Bottom Mount, ATX
