Cooler Master MWE 1050W V2 Gold Efficiency ATX3.0 PSU

Cooler Master MPE-A501-AFCAG-3EEU MWE 1050W V2 Gold Efficiency Fully Modular ATX3.1 RTX Ready PCIE5.1 12V 2X6 PSU (Active PFC/ 90% Efficiency )

80 PLUS Gold Efficiency
RTX Ready
140mm Silent Fan
High Temperature Resilience
Fully Modular Cabling

The new MWE Gold V2 1050, 1250 series is the next step in the evolution of Cooler Master’s entry level 80 Plus Gold Power Supply line which improves upon the original version in the places where users will see the most immediate benefit in terms of performance and stability for high end pc requirements.

Quiet Cooling
Silence Fan with Smart Temp. Controlling Feature
MWE Gold 1050 & 1250 are equipped with a 140mm silence fan with smart temperature controlling feature. The fan supports 0 RPM to achieve 0 noise based on the scenario.

High Temperature Resilience
MWE Gold V2 1050 series is able to push its temperature resilience to 50 degree Celsius safely. Such a high threshold greatly improves what’s possible to accomplish with the unit and your system in general. Overclocking and other high intensity applications become way more accessible when the system’s power supply unit can take the heat.

Model
MPE-A501-AFCAG
ATX Version ATX 12V V2.52
PFC Active PFC
Input Voltage 100-240V
Input Current 13-6A
Input Frequency 47-63Hz
Dimensions (L x W x H) 180 x 150 x 86 mm
Fan Size 140mm
Fan Bearing FDB
Fan Speed 2200 RPM
Noise Level @ 20% 0 dBA
Noise Level @ 50% 14.9 dBA
Noise Level @ 100% 27.3 dBA
Efficiency ?90% @ Typical Load
80 PLUS Rating 80 PLUS Gold
ErP 2014 Lot 3 Yes
Operating Temperature 0-50°C
Power Good Signal 100 – 150 ms
Hold Up Time >20ms at 100% Load
MTBF >100,000 Hours
Protections UVP / OVP / OPP / OTP / SCP / OCP
Regulatory TUV, cTUVus, CE, BSMI, FCC, CCC, EAC, RCM, KCC, CB, UKCA
ATX 24 Pin Connectors 1
EPS 4+4 Pin Connectors 1
EPS 8 Pin Connector 1
SATA Connectors 12
Peripheral 4 Pin Connectors 4
PCI-e 6+2 Pin Connectors 6
Series MWE Gold Series
Modular Fully Modular
80 Plus Efficiency Gold
Form Factor ATX
Watts 1050W
