Cooler Master X Silent MAX Platinum 1300W ATX3.1 PSU

Cooler Master MPS-D001-AFAP X Silent MAX Platinum 1300 ATX 3.1 Full Modular PSU, 1300W 80+ Platinum, 90° 12VHPWR 600W PCIe 5.1, Mobius 120 Fan, Infineon CoolMOS

Precise Silent Power
Introducing the X Silent MAX Platinum by Cooler Master, engineered with an acoustically optimized Mobius Fan, top-tier industrial IC components and our exclusive aluminum heatsink dissipation technology.
This combination not only achieves supreme silence, but also ensures a premium experience.

Supreme Silence
Our design integrates an ultra-silent Mobius fan with an exclusive aluminum heat sink for improved cooling efficiency. Combined with unique inductors that minimize electromagnetic noise, it ensures an exceptionally quiet experience.

Fully Modular Cabling
Modular cabling minimizes clutter, while the additional ports provide extra functionality.

Superior Cooling Performance
Our exclusive aluminum Thermal Mold efficiently disperses heat, while the ultra-silent Mobius fan strengthens the airflow to lower the temperature across the unit. This dual approach guarantees effective thermal management, maintaining optimal performance and extending the lifespan of the PSU.

Digital Power Management System & MasterCTRL
Equipped with MCUs and Integrated with MasterCTRL software, our reliable PSU meticulously monitors temperature, current load and efficiency in real-time, offering precise and direct oversight.

Active Bridge Rectifier Boosts Efficiency 2%
The Active Bridge Rectifier, equipped with the Infineon CoolMOS, marks a significant advancement in power efficiency. This innovative combination not only conserves electricity, but also significantly reduces power loss, outperforming traditional bridge diodes. It’s an ideal solution for users seeking eco-friendly, high-efficiency power supply units.

ATX 3.1 Support & two Dual-color 12V-2X6 Cables
Includes ATX 3.1 support and two dual-color 12V-2X6 connectors (with clear purple markings) help users confirm correct installation, preventing poor contact and power issues for enhanced safety and reliability.

ATX Version ATX 12V Ver. 3.1
PFC Active PFC
Input Voltage 100-240V
Input Current 15-7.1A
Input Frequency 50-60Hz
Dimensions (L x W x H) 180 x 150 x 86 mm
Fan Size 120mm
Fan Bearing LDB
Fan Speed 2050 RPM
Efficiency ? 92% @ Typical Load
80 PLUS Rating 80 PLUS Platinum
ErP 2014 Lot 3 Yes
Operating Temperature 0-50°C
Power Good Signal 100 – 150 ms
Hold Up Time ? 16ms
MTBF >100,000 Hours
Protections OPP/ OVP/ OTP/ OCP/ SCP/ UVP/ Surge & Inrush Protection
Regulatory cUL, TUV, CE, FCC, BSMI, CCC, EAC, RCM, UKCA/BIS, KC (based on region’s request.)
ATX 24 Pin Connectors 1
EPS 4+4 Pin Connectors 1
EPS 8 Pin Connector 1
SATA Connectors 12
Peripheral 4 Pin Connectors 4
PCI-e 6+2 Pin Connectors 4
12V-2×6 Connectors 2
USB 10P Connector 1
PMBus 5 Pin Connector 1
Series X Series
80 Plus Efficiency Platinum
Modular Fully Modular
Form Factor ATX
Watts 1300W
ATX Version ATX 3.1
Input Voltage Range Full Range
