Lian Li A3-mATX Mesh Black Steel Micro-ATX Mini Tower Black

Lian Li A3-mATX 26.3L Micro Form Factor Chassis-No Fans Included-Supports 360mm AIO-Modularity Design-for M-ATX, ITX Motherboard-DAN Cases -Black Model G99.A3X.00

Sporting a clean and sophisticated look, the Lian Li A3-mATX Mini-Tower Case in black saves room on your desktop or entertainment center. For builders looking for a full, robust experience in a smaller form factor, the A3-mATX offers support for resource-hungry components without compromising performance. The front panel is made of a sophisticated black walnut trim, providing a balance of style and functionality.

Designed to leverage every inch of its compact design, the A3-mATX supports Mini-ITX and Micro-ATX motherboards as well as ATX power supplies. Four expansion slots accommodate graphics cards up to 16.3″ in length and there is 6.4″ of clearance for CPU coolers. While the A3-mATX sports a breathable design, up to ten 120mm fans or a 360mm radiator may be installed to enhance airflow and balance thermal performance. Connect essential devices such as controllers and external drives to the two USB-A ports and one USB-C port. Separate 3.5mm audio output and microphone input jacks enable easy communication for conference calls or gaming.

Fully Customizable, Fully Compatibility
With its relocatable PSU bracket, the A3-mATX allows you to build a PC tailored to your needs. All the panels (sides and top) are removable, giving you a clean 360° view of your internals, and the case can accommodate large components.
Adaptable Storage Solutions
The A3-mATX provides three drive bays to meet storage needs in a comprehensive build. The removable SSD tray uses the same mounting point as the PSU bracket and can be relocated as needed. The bottom of the case can hold one SSD or HDD.

Minimalistic sleek design 26.3L micro form factor chassis
Side and top panels are designed with steel mesh
Accommodates M-ATX and ITX motherboard with 4 slots 415mm large GPU
Supports up to 360 radiator and 10 x 120mm fans
Supports ATX/SFX/SFX-L and LIAN LI Edge PSU that can be mounted sideways or frontways
In collaboration with DAN Cases for the case design whereas manufactured and sold by LIAN LI.

WELL VENTILATED, MINIMALIST DESIGN
With three sides featuring minimalist mesh panels and a sleek front panel,
the A3-mATX combines functionality with style,
making it the perfect touch to your setup.

COMPACT DESIGN,MASSIVE POTENTIAL 26.3L
Dive into the realm of compactness with the A3-mATX,
which unlocks the potential of a small form factor PC case.

EFFORTLESS MODULARITY, STREAMLINED BUILDS
The toolless removal of all exterior panels and modular brackets provide easier access for installation and cable management. With a removable bottom dust filter, ensuring the system stays clean and efficient.

VERSATILE COMPATIBILITY, ULTIMATE CUSTOMIZATION
Unleash your creativity with the flexible compatibility A3-mATX without compromising on high-performance, large size components.

The A3-mATX case accommodates a maximum CPU cooler height of 165mm and a 4-slot thick GPU with a maximum length of 415mm. Note that with a 25mm thick fan installed at the bottom, the GPU thickness will be limited to 61mm, allowing for only a 3-slot GPU. Additionally, when installing a radiator and fan combo, there will be no space for the GPU.

SPACE MAXIMIZED FOR COOLING
Maximizing the cooling capacity of this 26.3 liter case, 360mm AIO can be mounted to efficiently cool high-end components.

FLEXIBLE PSU INSTALLATION
Offers multiple mounting slots for a maximum of 220mm ATX/SFX/SFX-L or LIAN LI Edge PSU for ideal PSU placement to best suit your build requirements.

ADAPTABLE STORAGE SOLUTIONS
Provides 3 drive bays to meet storage needs in a comprehensive build.

REMOVABLE SSD TRAY
Use the same mounting point as the PSU bracket,
can relocate as needed.
2 × 2.5″ SSD

BOTTOM DRIVE SPACE
Offers a mounting point at the bottom of the chassis.
1 × 2.5″ SSD or 1 × 3.5″ HDD

SEAMLESS CONNECTIVITY, STYLISH IO
With its front IO featuring essential ports and buttons, along with a sleek and stylish front panel design, the A3-mATX ensures seamless connectivity while showcasing on the desk.

A DAN CASES COLLABORATION
Combining the design of Daniel Hansen from DAN Cases with LIAN Li’s manufacturing prowess, the collaboration brings the A3-mATX to life.

CASE TYPE MFF (Micro Form Factor)

DIMENSION (D) 443mm x (W) 194mm x (H) 321.5mm
(D) 443mm x (W) 194mm x (H) 306mm(w/o feet)

CAPACITY 26.3L

MATERIAL Steel

MOTHERBOARD SUPPORT M-ATX/ITX
PSU SUPPORT ATX/SFX/SFX-L (Max 220mm)
FAN SUPPORT
Top: 3 x 120mm
Side: 3 x 120mm or 2 x 140mm
Bottom: 3 x 120mm
Rear: 1 x 120mm

RADIATOR SUPPORT
Top: 1 x 360/240mm
Side: 1 x 360/280/240mm
Bottom: 1 x 240mm (360mm with fan at the bottom)

DRIVE SUPPORT
Tray: 2 × 2.5″ SSD
Bottom: 1 × 2.5″ SSD or 1 × 3.5″ HDD

GPU LENGTH CLEARANCE Max 415mm
CPU HEIGHT CLEARANCE Max 165mm

EXPANSION SLOTS 4

I/O PORTS
1 x Power Button
2 x USB 3.0 TYPE-A
1 x USB 3.1 TYPE-C
1 x Mic
1 x HD Audio
DUST FILTER 1 x Bottom / 1 x Front

Manufacturer’s Product-Link
