Lian Li HydroShift II OLED Curved 360 Fanless White

Lian Li Hydroshift II OLED Curved 360 Motorized Liquid CPU Cooler – Flexible Slide-Tube Clamp Coolant Pathway – Adjustable 6.67″ 2K Screen – 3D Animation Effects – LGA 1851/1700, AMD AM5/4 – Fanless White (GHS2OLDC36NW)

Immersive Curved OLED Display: Experience stunning visuals on a 6.67″ 2K curved OLED panel with vibrant colors and high contrast, delivering up to 500 nits brightness for exceptional clarity in any lighting.
Motorized Control for Customization: Adjust the viewing angle effortlessly with the motorized pump head, featuring lift, rotation, and dual-axis movement, all managed through the intuitive L-Connect 3 software, allowing for a personalized setup.
Innovative Hot-Swappable Design: Simplify installation with a magnetic hot-swappable display module that uses spring-pin connectors, enabling easy attachment and removal without powering down, perfect for reducing damage risks during assembly.
Compact and Efficient Radiator: The 400 × 122 × 24 mm radiator fits approximately 90% of mainstream cases while maintaining optimal cooling performance, combined with durable server-grade tubing and adjustable routing options.
Versatile Fan Compatibility: Choose from multiple fan configurations, including Fanless, UNI FAN P28 V2, and UNI FAN TL FLEX versions, ensuring efficient cooling tailored to your system’s needs for peak performance.

6.67″ 2K 60Hz curved OLED screen with built-in 3D visual effects.
Motorized pump head supports vertical and horizontal angle adjustment.
Magnetic hot-swappable display module for easier installation and upgrades.
L-Connect 3 enables screen, theme, layout, lighting, and motorized control.
High-performance pump runs up to 2400 RPM, or 2800 RPM in Turbo Mode.
Available in UNI FAN TL FLEX, UNI FAN P28 V2, and fanless versions.
UNI FAN TL FLEX balances airflow, pressure, and noise.
UNI FAN P28 V2 delivers stronger cooling with speed control and RPM lighting feedback.
Slim radiator and side-mounted tubing improve compatibility and build cleanliness.

Motorized Control. Perfect Angle
HydroShift II OLED Curved features motorized vertical and horizontal adjustments for optimal viewing angles. With L-Connect 3, the pump head can be precisely positioned to fit any build.

Magnetic Hot-Swappable Display Module
The magnetic display module uses pogo-pin connectors for secure attachment and removal.
It can be installed after the system is fully built, reducing the risk of damage during assembly or transport, while making upgrades easier and safer.

UNLEASH YOUR FULLY PERSONALIZED SETUP
Powered by L-Connect 3, the curved OLED screen delivers a more immersive and flexible user experience with dynamic content support, customizable layouts, motorized adjustment, and integrated control of display, cooling, and lighting.

2D and 3D Full-Screen Themes
Offers diverse 2D and 3D themes, turning the curved OLED display into a seamless full-screen canvas.

Dynamic & Static Content with Immersive Layered Visuals
Support for dynamic and static content enables rich, expressive layouts, giving users greater creative freedom and easier content customization. Flexible layering seamlessly combines animations, themed visuals, and information modules, allowing users to build engaging displays quickly, with dual video overlap adding depth and stronger visual impact.

Personalized Custom Theme with Modular Editing
Upload your own background and build a custom dashboard with dynamic or static theme info modules. Choose your data, adjust each module’s look, and arrange every element to match your system style.

Dual and Triple Split Layouts
Maximize your screen real estate with flexible dual and triple-split layouts that allow you to divide the curved OLED display into multiple independent zones. Each section is fully customizable, giving you the freedom to select personalized backgrounds and display your choice of dynamic animations or static hardware metrics.

Integrated Ambient Lighting
Soft ambient lighting enhances the display area with a refined glow, creating a more immersive visual experience while complementing the overall system aesthetic.

High-Performance Pump with Turbo Boost
Operating at up to 2400 RPM, the upgraded pump ensures efficient coolant circulation and stable heat transfer while running 2 dBA quieter than HydroShift II LCD-S.

Turbo Mode
For demanding workloads, Turbo Mode increases pump speed up to 2800 RPM, providing additional thermal headroom for high-performance systems.

Compact Radiator, Broad Compatibility
The slim 400 × 122 × 24mm radiator is engineered with a single-wave fin design to improve case compatibility across mainstream chassis. Its reduced footprint makes installation easier without compromising thermal efficiency.

Hidden Tube Routing for a Streamlined Build
HydroShift II OLED Curved Series features side-mounted tubing to reduce visual clutter. Paired with the white O11 EVO RGB, components align neatly in the top chamber, highlighting the hardware, lighting, and OLED display.

Perfect Fit for O11 Vision Compact
HydroShift II OLED Curved supports flexible side-mounted radiator installation, perfectly suited for triple-glass showcase cases like the O11 Vision Compact, delivering a clean and refined build aesthetic.

BROAD COMPATIBILITY,SEAMLESS SUPPORT
HydroShift II OLED Curved offers easy installation and broad CPU socket compatibility, featuring an upgraded AM4/AM5 bracket that ensures even pressure and improved thermal performance.

SPECIFICATIONS

DISPLAY TYPE 6.67″ OLED
DISPLAY RESOLUTION 2288 x 1048 pixels
BRIGHTNESS 500 nits
PUMP HEAD DIMENSION 126.5 × 87.1 × 108mm
PUMP SPEED 1600-2800RPM+10%
PUMP NOISE LEVEL < 30.0 dBA (Max)
RADIATOR DIMENSIONS 400 × 122 × 24mm
RADIATOR DESIGN Single-wave
RADIATOR MATERIAL Aluminum
TUBE LENGTH 450 / 475mm
CPU SOCKECT COMPATIBILITY Intel LGA 1700 / 1851
AMD AM4 / AM5
