Lian Li Lancool 207 Digital Black ATX Case with Glass Side Panel

Lian Li Lancool 207 Digital Black ATX Case with Glass Side Panel Model G99.LAN207DX.00

6″ LCD at the bottom of the panel: 60Hz refresh rate, 720×1600 pixels resolution, and 500 nits brightness.
M-ATX sized case with ATX compatibility
Included 2 x 140mm PWM fans at the front, and 2 x 120mm PWM fans at the bottom
Supports 360 radiator on the top and GPU up to 375mm long
Motherboard tray position redesigned slightly lower into the PSU shroud with two bottom fans placed directly under the GPU for better cooling
Well ventilated mesh panels on the front, top, and bottom, enhancing airflow
Unique front PSU Installation
GPU Anti-sag Bracket Included

The LANCOOL 207 Digital adds a playful touch to the LANCOOL 207, featuring an integrated LCD screen for real-time system monitoring and customizability – all within a sleek and compact M-ATX chassis.

ATX LAYOUT RE-INVENTED
Though compact in size, the LANCOOL 207 Digital offers remarkable compatibility, supporting ATX motherboard, a 360mm radiator, ATX PSU, and GPU up to 375mm long, all within its 45.5L chassis.

6 – INCH LCD SCREEN
This 6” LCD screen features a 60Hz refresh rate, a 720×1600 resolution, and 500 nits of brightness. It offers extensive customization options and can display a wide range of hardware information in real time.

Real-Time Performance, Personalized Display
Choose from nearly 30 built-in templates for a quick and polished setup. You can also import “third-party” templates.

For a fully personalized experience, L-Connect 3 features a powerful built-in canvas tool that lets you design your display your way. Freely arrange modular elements, craft a layout that fits your style, and even upload your favorite images to make your setup truly one of a kind.

The screen can also function as a 60Hz secondary display, perfect for monitoring or multitasking. Users can easily toggle the secondary screen function ON or OFF directly within the L-Connect 3 interface.
The screen is also allowed to be as a secondary screen (60hz refresh rate) by L-connect 3 control.

The screen function also includes fan speed dashboard. Fans can be custom-named for easy identification, with clearly displayed positions for quick recognition. Real-time RPM and temperature source readings enable precise monitoring and fine-tuning of cooling performance.

SPACE-SAVING INNOVATIVE LAYOUT
The LANCOOL 207 Digital’s unique offset motherboard tray provides a space-efficient solution while improving compatibility and airflow.

EASY ACCESS FRONT-MOUNTED PSU
The PSU is strategically placed at the front, with connector ports facing outward for convenient cable connection. Additionally, a PSU power adaptor extension cable is provided for rear power access.

OPTIMAL AIRFLOW DESIGN
Besides being designed with comprehensive mesh panels on the top, front, and side bottom, the LANCOOL 207 digital comes pre-installed with four high-performance fans for superior out-of-box cooling.

GPU ANTI-SAG BRACKET SUPPORT
The LANCOOL 207 Digital includes an adjustable GPU anti-sag bracket, offering extensive adjustability to fit GPUs of all sizes.

SEAMLESS CONNECTIVITY
The LANCOOL 207 Digital’s top-mounted I/O panel offers easy access to essential ports.

EFFICIENT CABLE MANAGEMENT
With the innovative layout, the well-organized cable management system is mostly at the front of the 2nd chamber.

Front Dust Filter – LAN207-1X
For next level dust prevention, a front panel dust filter is available as an optional accessory. It fits seamlessly behind the front fan, providing an extra layer of protection.

SPECIFICATIONS

MODEL NAME LAN207DX
DIMENSION (D) 455.6mm x (W) 219mm x (H) 456mm
MATERIAL Steel/ 4.0mm Tempered Glass
EXPANSION SLOTS 7
MOTHERBOARD SUPPORT Standard ATX ( Width Max 244mm ) / Micro-ATX/Mini-ITX
PSU SUPPORT (Under 160mm)
FAN SUPPORT Front: 140mm x 2
Top: 120mm x 3 or 140mm x 2
Above PSU Shroud: 120mm x 2
Rear: 120mm x 1
RADIATOR SUPPORT Top: 360/280/240mm
DRIVE SUPPORT 2x 3.5″ HDD or 2.5″ SSD
GPU LENGTH CLEARANCE 375mm (Max.)
CPU HEIGHT CLEARANCE 180mm (Max.)
I/O PORTS USB 3.0 × 2
USB 3.2 TYPE-C × 1
Audio × 1
Power Button × 1
DUST FILTER 1 x Bottom
SCREEN 6 inch
SCREEN RESOLUTION 720×1600 pixels
SCREEN REFRESH RATE RATE 60Hz
SCREEN BRIGHTNESS 500nits
