MSI MAG X870E TOMAHAWK WIFI AMD AM5 ATX Motherboard ; 4x DDR5 UDIMM 8400+ MT/s (OC) ; PCIe 5.0 slot

Expert Features AMD Ryzen Ready : Supports AMD Ryzen™ 9000 / 8000 / 7000 Series desktop processors on the AM5 platform for powerful gaming and creator builds. Next-Gen X870E Platform : Built on AMD X870E chipset with DDR5, PCIe 5.0, USB4, Wi-Fi 7, and 5G LAN for a serious future-ready PC. Strong CPU Power Delivery : 14+2+1 power phase design with 80A Smart Power Stage keeps high-end Ryzen CPUs stable under heavy load. DDR5 8400+ OC Support : Supports fast DDR5 memory up to 8400+ MT/s OC depending on CPU and RAM configuration. PCIe 5.0 GPU Slot : Main PCIe slot supports PCIe 5.0 x16 with Ryzen™ 9000 / 7000 processors for next-generation graphics cards. Ultra-Fast M.2 Storage : Includes 4x M.2 slots with PCIe 5.0 and PCIe 4.0 support for fast NVMe SSD setups. USB4 40Gbps Ports : Rear USB4 Type-C ports support up to 40Gbps transfer speed for modern high-speed devices. Wi-Fi 7 + 5G LAN : Gives you both ultra-fast wireless and high-speed wired networking for gaming, streaming, and large downloads. Premium Cooling Design : Extended heatsinks, M.2 Shield Frozr, and 7W/mK thermal pads help keep the motherboard stable under pressure. EZ DIY Features : EZ M.2, EZ PCIe Release, EZ Antenna, and pre-installed I/O shield make building and upgrading much easier. Audio Boost 5 : Realtek® ALC4080 audio delivers 7.1-channel high-performance sound for gaming and media. Debug LEDs : EZ Debug LED and EZ Digit Debug LED help quickly identify problems during setup or boot. EXPERT SPECIFICATION OPERATING SYSTEM Support for Windows® 11 64-bit Manufacturer Number MAG X870E TOMAHAWK WIFI Product Condition New CPU Supports AMD Ryzen™ 9000/ 8000/ 7000 Series Desktop Processors Chipset AMD X870 CPU Socket Socket AM5 Form Factor ATX Memory 4 x DDR5 UDIMM, Maximum Memory Capacity 256GB Memory Support DDR5 8400 – 5600 (OC) MT/s / 5600 – 4800 (JEDEC) MT/s Ryzen™ 9000 Series Processors max. overclocking frequency: 1DPC 1R Max speed up to 8400+ MT/s 1DPC 2R Max speed up to 6400+ MT/s 2DPC 1R Max speed up to 6400+ MT/s 2DPC 2R Max speed up to 4800+ MT/s Supports AMD POR Speed and JEDEC Speed Supports Memory Overclocking and AMD EXPO Supports Dual-Channel mode Supports Non-ECC, Un-buffered memory Supports CUDIMM, Clock Driver bypass mode only CUDIMM support and POR boot frequency may vary by CPU series, with manual overclocking available after boot. Certain CPUs may fail to boot, but future BIOS updates will improve compatibility. The DIMM slots on this motherboard have double-sided latches. Memory compatibility and supported speeds can vary depending on the CPU and memory configuration. For detailed information, please refer to the Memory Compatibility List available on the product’s Support page or visit https://www.msi.com/support/. LAN 1 x Realtek® 8126 5G LAN Wireless LAN Wi-Fi 7 The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz* (320MHz) up to 5.8Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax/ be Bluetooth Supports Bluetooth® 5.4, MLO, 4KQAM 6GHz band support may depend on every country’s regulations and Wi-Fi 7 will be ready in Windows 11 version 24H2. The Bluetooth version may be updated, please refer to the Wi-Fi chipset vendor’s website for details. Bluetooth 5.4 will be ready in Windows 11 version 24H2. Audio Realtek® ALC4080 Codec 7.1-Channel USB High Performance Audio Supports up to 32-bit/384kHz playback on front panel Supports S/PDIF output STORAGE 2 x M.2 Gen5 x4 128Gbps slots 2 x M.2 Gen4 x4 64Gbps slots 4 x SATA 6Gbps ports Onboard Graphics 1 x HDMI™ Support HDMI™ 2.1 FRL, maximum resolution of 8K 60Hz 2 x Type-C DisplayPort USB4® port, supporting DisplayPort 1.4 with HBR3 over USB Type-C, maximum resolution of 4K 60Hz Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed. RAID – I/O (Rear) Clear CMOS Button USB 10Gbps Type-A USB 5Gbps Type-A USB 2.0 5G LAN Wi-Fi / Bluetooth Audio connectors Flash BIOS Button HDMI™ USB 40Gbps Type-C USB 10Gbps Type-C USB 10Gbps Type-A Expansion Slots 3 x PCI-E x16 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) PCI_E1 slot Supports PCIe 5.0 x16 (For Ryzen™ 9000/ 7000 Series processors) Supports PCIe 4.0 x8 (For Ryzen™ 8700/ 8600/ 8400 Series processors) Supports PCIe 4.0 x4 (For Ryzen™ 8500/ 8300 Series processor) USB (Front) 4 x USB 5Gbps Type A 1 x USB 20Gbps Type C 4 x USB 2.0 USB (Rear) 3 x USB 5Gbps Type A 2 x USB 10Gbps Type A 1 x USB 10Gbps Type C 2 x USB 40Gbps Type C 4 x USB 2.0 Internal Connectors 1 x Power Connector(ATX_PWR) 2 x Power Connector(CPU_PWR) 1 x Power Connector(PCIE_PWR 8pin) 1 x Front Type-C Quick Charge Connector(PD_PWR1) 1 x CPU Fan 1 x Combo Fan (Pump_Sys Fan) 6 x System Fan 1 x EZ Conn-header (JAF_2) 2 x Front Panel (JFP) 1 x Chassis Intrusion (JCI) 1 x Front Audio (JAUD) 3 x Addressable V2 RGB LED connector (JARGB_V2) 1 x RGB LED connector(JRGB) 1 x TPM pin header(Support TPM 2.0) 4 x USB 2.0 ports 4 x USB 5Gbps Type A ports 1 x USB 20Gbps Type C ports Dimensions 9.60″ x 12.00″
