NZXT F360 RGB Core 360mm Single-Frame RGB Fan Unit White

NZXT RF-U36HF-W1 F360 RGB Core – 360mm Single-Frame Fan Unit with 3 x 120mm RGB Fans – Speed & Lighting Control – High Static Pressure & Airflow – Fluid Dynamic Bearings – 8 aRGB LEDs Per Fan – White

NZXT F Series RGB Core single-frame fans seamlessly integrate multiple fans for effortless installation while offering superior cooling, whisper-quiet performance, and striking RGB visuals.

Single-frame unit with integrated fans streamlines installation, setup, and lighting control—no need to connect individual fans.
Simply connect a single cable to an NZXT controller (sold separately) for lighting and speed control via NZXT CAM software. Or, connect to any motherboard’s 5V ARGB header using the included splitter cable.
Fan blade design boosts static pressure to push air through tight spaces while ensuring optimal airflow. Suitable for both intake and exhaust.
Fluid dynamic bearings ensure quiet, stable operation across an exceptional 60,000 hour lifespan.
Eight individually-addressable RGB LEDs per fan hub are diffused through semi-translucent blades for brilliantly colorful visuals.
PWM-controlled fans dynamically adjust spinning speeds based on PC temperatures for optimal efficiency and reduced noise.
Anti-vibration rubber corners effectively eliminate noise caused by vibrations for hushed performance at any speed.
Control lighting and fan speeds via CAM software when connected to an NZXT controller (sold separately).

Speed: 500 – 2,400 ± 250 RPM per fan
Airflow: 75.12 CFM per fan
Static Pressure: 3.3 mm H?O per fan
Noise: 30.00 dBA per fan
Power Consumption: 12V DC, 0.79A, 9.48W / 5V DC, 0.81A, 4.05W
Bearing: Fluid Dynamic Bearing
Output LED: 8 LEDs per Fan
Connector: 8-pin for PWM & RGB
Cable Length: 1 x 600 mm
Material: Plastic, Rubber, PCB
Life: 60,000 Hours

RGB Core Fan
Mounting Screws x4
Splitter Cable

Tech Specs

Dimensions
Height 360 mm
Width 120 mm
Depth 26 mm

Fans
Speed 500 – 2,400 ± 250 RPM per fan
Airflow 75.12 CFM per fan
Static Pressure 3.3 mm H?O per fan
Noise 30.00 dBA per fan
Power Consumption 12V DC, 0.79A, 9.48W / 5V DC, 0.81A, 4.05W
Bearing Fluid Dynamic Bearing
Output LED 8 LEDs per Fan
Connector 8-pin for PWM & RGB
Cable Length 1 x 600 mm
Material Plastic, Rubber, PCB
Life 60,000 Hours

Cable
Splitter Cable Connections & Cable Length 4-pin PWM Fan Cable (1 x 300 mm) / 5V RGB & 4-pin NZXT RGB Cable (1 x 100 mm)
