NZXT H7 Flow RGB Edition White Mid-Tower Airflow Case

NZXT H7 Flow RGB White Mid-Tower Airflow PC Gaming Case – CM-H72FW-R1 – with 360mm RGB Single Frame Fan Supports Bottom Fans for Direct GPU Cooling – Cable Management

The H7 Flow RGB revolutionizes GPU cooling in a classic mid-tower form factor. Its vertical PSU layout allows space for 3 x 120mm bottom fans, offering efficient cooling without expanding the case footprint.

Supports three bottom-mounted 120mm fans for direct GPU cooling while retaining a narrow mid-tower footprint.
Comes equipped with a F360 RGB Core single-frame fan for exceptional out-of-the-box cooling and RGB lighting.
High-performance mesh panels maximize airflow for both intake and exhaust, as well as filter dust.
Supports up to 420mm radiators in the front and 360mm radiators in the top for powerful cooling potential.
Intuitive cable management system with wide channels, built-in hooks, and included straps for easy routing.
Capacity for up to 10 fans in total: 3 up top, 3 in front, 3 on bottom, and 1 in the rear.
Conveniently access 2 x USB-A and 1 x USB-C ports located on the top panel.
Tool-less access to the front, top, and side panels makes building and upgrading a breeze.

Key Specs
Motherboard Support: E-ATX (Up to 277mm), ATX, Micro-ATX, Mini-ITX
Enclosure Type: Mid-Tower
Case Material: SGCC Steel, Ultra-Clear Tempered Glass (White), Dark Tinted Tempered Glass (Black)
Height (With Feet): 544 mm
Width: 244 mm
Depth: 468 mm
Weight: 11.13 kg

Inside the Box
H7 Flow RGB
F360 RGB Core (pre-installed, case version)
Installation Accessories
Manual

Tech Specs
Key Specs
Motherboard Support E-ATX (Up to 277mm), ATX, Micro-ATX, Mini-ITX
Enclosure Type Mid-Tower
Case Material SGCC Steel, Ultra-Clear Tempered Glass (White), Dark Tinted Tempered Glass (Black)
Dimensions Height (With Feet) 544 mm
Width 244 mm
Depth 468 mm
Weight 11.13 kg

Compatibility & Clearance
CPU Cooler Height Up to 185mm
GPU Length Up to 410 mm
PSU Length Up to 200 mm
Cable Management Up to 34.5 mm
Top Mounted Radiator & Fan Combined Thickness Up to 57 mm (140mm / 280mm)

Front I/O Ports

USB 3.2 Gen 1 Type-A 2
USB 3.2 Gen 2×2 Type-C (20 Gbps) 1
Headset Audio Jack 1

Expansion Slots

Standard 7
Vertical 0

Drive Bays
2.5″ 2+2
3.5″ 2

Fan Support
Front 3 x 120 mm / 3 x 140 mm (1 x F360 RGB Core included)
Top 3 x 120 mm / 2 x 140 mm
Bottom 3 x 120 mm
Rear 1 x 120 mm / 1 x 140 mm
Filters High-Performance Mesh

Radiator Support
Front Up to 420 mm
Top Up to 360mm
Rear Up to 140mm

Fan Specs – F360 RGB Core (Case Version)
Model F360 RGB Core Fan (Case Version)
Speed 1,700 ± 200 RPM
Airflow 50.1 CFM
Static 1.27 mm-H?O
Noise 23.3 dBA
Fan Connector 3-pin DC
