Unitek uHUB15+ USB-C Triple 4K KVM Docking Station

Unitek D1106AGY01 USB-C 10Gbps Dual Host Switch Functional Univeral Docking Station(HDMI*2+DP UP 4K60HZ with Mst)+Gigabit Ethernet+SD3.0/Micro SD3.0 Dual-LUN Card Reader+1*USB-A – 5Gbps+2A1C 10Gbps HUB+Audio+PD 100W, HDMI to VGA Converter, Space Grey, flip-top color box

Connect two USB-C laptops to three 4K monitors (2x HDMI, 1x DP) and enjoy seamless switching. With 100W power delivery and multiple ports, it enhances connectivity and productivity.

Features Point
Dual Hosts Control
Triple 4K Display Output
100W Power Delivery Charging
High-Speed Data Transfer

Boost Your Workspace with the UNITEK USB-C Triple 4K KV Docking Station. Connect two USBC laptops to triple 4K monitors (HDMI x2, DP x1) for stunning visuals. With one USB-C and two USB-A ports, plus 100W power delivery (PD), it ensures efficient charging and connectivity. Easily switch between laptops to enhance your workflow and maximize productivity.

Dual Hosts Control
Effortlessly control two laptops or PCs using a single mouse, keyboard, and monitor(s). Switch quickly between two PCs with the press of a host button.

Triple 4K Display Output
A single/dual display output (2x HDMI/HDMI + DP) accommodates resolutions at 4K@60Hz (backward compatible). When connected to three monitors, it supports two paths at 4K@60Hz and one path at 4K@30Hz.

Supports Triple 4K Display
The UNITEK USB-C Triple 4K KV Docking Station supports up to three video output interfaces. It features MST/SST* and HDCP v2.2/DP++ support, and the included HDMI to VGA video adapter allows for easy connection to a VGA monitor.
*Please note that MST capability is available for Windows users only.

100W Power Delivery Charging
Enjoy up to 100W Power Delivery pass-through, allowing you to power and charge your USB-C laptop or host.

High-Speed Data Transfer
Equipped with three USB ports (2x USB-A + 1x USB-C) at 10Gbps and one USB-A port at 5Gbps for fast data transfer.

Comprehensive Port Selection
The docking station includes an RJ-45 Gigabit Ethernet port. The 3.5mm mic/audio jack provides high-quality audio output with microphone capabilities. Built-in SD and Micro-SD 3.0 card slots allow easy access to files from universal SD and MicroSD memory cards, supporting simultaneous reading from two cards.

System Compatibility
Compatible with Windows 10/11 (32/64-bit) and macOS 10.6 or above.

Multi-Monitor Setup
Experience seamless multi-monitor productivity with UNITEK docking stations. On Windows, enjoy MST (Multi-Stream Transport) mode supporting up to 4 extended displays (AB, ABC, ABCD) or mirrored setups (AA, AAA, AAAA). On macOS, use Daisy Chain for mirrored (AA, AAA, AAAA) and extended configurations (AB, ABB, ABBB).

Works With Windows 7/8/10/11 (32/64bit), Linux kernel 3.x, Mac OS 10.6 or above
Host Power (PD) USB-C PD 100W
Max Output Resolution Single/ Dual Display up to 4K@60Hz, Triple Display (4K@60Hz x 2, 4K@30Hz x 1)
HDMI 2
DisplayPort 1
USB-A 2 x 5Gbps, 1 x 10Gbps
USB-C 3 x 10Gbps (2 x Host), 1 x PD 100W, 1 x DC5V
SD card slot 1
Micro SD card slot 1
3.5mm Aux jack 1 (Audio In/ Out)
Ethernet RJ45 Jack 1000Mbps
KVM Yes
Cable Length 1M, 60CM
Cable Type USB-C to USB-C Cable
Power Supply 5V3A
Power Source USB-C
Dimensions 290.0mm x 80.0mm x 17.6mm
Material Aluminum Alloy
Color Space Grey

What’s In the Box
1 x uHUB15+ USB-C Triple 4K KVM Docking Station;
1 x USB-C to C Cable (100cm)
1 x USB-C to C Cable (60cm)
1 x HDMI to VGA video adaptor
1 x User Manual
