HP Pavilion 24-G020 All-in-One Am A8 Touch White

HP PAVILION 24-G020 ALL-IN-ONE AM A8 TOUCH WHITE Product Release Information Product Number V8P00AA Display 60.45 cm (23.8 in) 10-point touch-enabled diagonal widescreen full high-definition IPS WLED-backlit edge-to-edge display Size: 60.45 cm (23.8 in) diagonal Display resolution: 1920 x 1080 Motherboard Bali-U Figure : Bali-U motherboard Form factor: Customized: 15.0×14.0 cm (5.9×5.5 in) Chipset: combined with the processor Memory sockets: 2 x DDR3L Expansion Slots: One M.2 slot for WLAN For more details, see Bali-U motherboard specifications . Processor AMD Carrizo-L A8-7410 CPU speed: 2.2 GHz (2.5 GHz max turbo boost) CPU cores: 4 CPU Cache: 2 MB TDP: 15 W (cTDP: 12 W/25 W) System on a Chip (SoC) design – chipset and processor are combined Integrated graphics: AMD Radeon R5 Series Memory 8 GB Amount: 8 GB Speed: PC3L-12800 MB/s Type: DDR3L-1600 Memory upgrade information Single channel memory architecture One DDR3L SODIMM (204-pin) socket Supports up to PC3L-12800 (DDR3L-1600) Supports 2 GB, 4 GB, and 8 GB SODIMMs Supports up to 4 GB on 32-bit systems NOTE: 32-bit systems cannot address a full 4.0 GB of memory. Supports up to 8 GB on 64-bit systems NOTE: Maximum memory shown reflects the capability of the hardware and can be limited further in the operating system. Video Graphics Integrated graphics Integrated graphics are based on the processor. AMD E2-7110 : Integrated Radeon R2 Series Graphics AMD A6-7310 : Integrated Radeon R4 Series Graphics AMD A8-7410 : Integrated Radeon R5 Series Graphics Sound/Audio Integrated audio Audio Codec: Realtek ALC3252 Audio jack presence detection Speakers Integrated speakers Networking Integrated Bluetooth 4.0 and Wireless LAN 802.11b/g/n featuring 2.4 GHz 1×1 technology Interface: M.2 Transmission standards: 802.11 b/g/n Single band: 2.4 GHz LAN: 1000BASE-T Technology: Realtek RTL8161GSH Data transfer speeds: up to 10/100/1000 Mb/s Transmission standards: 1000BASE-T Gigabit Ethernet Hard Drive 1 TB Size: 1 TB Interface: SATA Rotational Speed: 7200 rpm CD/DVD Disc Drive Ultra Slim Tray SuperMulti DVD Burner drive Memory Card Reader 3-in-1 Memory card reader Figure : View of memory card reader Supports the following cards: Secure Digital (SD) Secure Digital High Capacity (SDHC) SDXC Computer Case All-in-One Height: 42.4 cm (16.7 in) Width: 58.2 cm (22.9 in) Depth: 19.6 cm (7.7 in) Weight: 6.45 kg (14.21 lbs) unpackaged Front of the system Figure : Front of the system Webcam and microphone Screen Optical drive Speakers Power button Back of the system Figure : Back of the system Optical drive Power button Back I/Os Stand Left side of the system Figure : Left side of the system Right side of the system Figure : Right side of the system Optical drive Power Supply External 65 W (100V-240V) Total wattage: 65 W Output voltage: 19.5 V Output amps: 3.3 I/O Ports Back I/O ports Figure : ProstT 24 back I/O ports Lock slot Disk activity LED USB 2.0: 2 LAN (Ethernet) Power LED DC power in USB 3.0: 2 HDMI Headphone/Microphone Keyboard, Mouse and Input Devices HP USB keyboard Interface: USB Dimensions (approximately): Special buttons*: HP USB optical mouse Interface: USB Dimensions (approximately): Cable length: 1.8 m (5 ft, 11 in) Length: 114.6 mm (4.5 in) Width: 63.2 mm (2.5 in) Height: 37.2 mm (1.5 in) HP Webcam Figure : HP Webcam Webcam Webcam activity LED Microphones Operating System Microsoft Windows 10 Home High End (64-bit)
